SENSO high temperature pressure transmitter upto 150 degree c

Send Inquiry

Request To Call Back

SENSO high temperature pressure transmitter upto 150 degree c

Name: SENSO high temperature pressure transmitter upto 150 degree c
Brand: R S SALES & SERVICES
Price: 15000 INR
Availability: InStock

Price 15000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

SENSO high temperature pressure transmitter upto 150 degree c Specification

Resistance
500

Output
4-20 mA / 0-10 V

Theory
Pressure Sensor

Type
High Temperature Pressure Transmitter

Accuracy
0.25% F.S.

Operating Voltage
12-36 VDC

Output Voltage
0-10 V

Compensated Temperature
+20C to +85C

Storage Temperature
-40C to +150C

Operating Temperature
-40C to +150C

Material
Stainless Steel 316L

Overload Pressure
150% F.S.

Process Connection
G1/2", G1/4", M201.5, or customized

Medium Compatibility
Corrosive & Non-corrosive liquids and gases

Response Time
1 ms (10%~90%)

Electrical Connection
DIN43650, Packard, M12x1, Cable outlet

Long-Term Stability
0.2% F.S./year

Ingress Protection
IP65 / IP67

Pressure Range
0-10 bar / 0-60 bar / customized

SENSO high temperature pressure transmitter upto 150 degree c Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

About SENSO high temperature pressure transmitter upto 150 degree c

The SNSO-12 Series is engineered for precision measurement in demanding industrial and hydraulic environments for high temp applications. Designed to withstand harsh medium influences, this series offers exceptional reliability and long-term stability even when subjected to extreme pressure peaks and cavitation. SNSO-12 Sensor Accuracy typical: 0.50% FS Corrosion-proof Ceramic material / SS 316 Pressure ranges from 0 up to 600 bar Response time max: 4ms IP65/IP67 Enclosure rating

Exceptional High Temperature Reliability

SENSO high temperature pressure transmitters maintain unsurpassed accuracy and stability even in environments reaching 150C. Built with stainless steel 316L, these transmitters are designed to handle corrosive or non-corrosive liquids and gases, delivering precise readings without performance degradation.

Versatile Connectivity and Pressure Ranges

Offering extensive compatibility, the transmitter supports process connections such as G1/2'', G1/4'', M201.5, or fully customized options. Pressure ranges are available in 0-10 bar, 0-60 bar, or according to your requirements, making the device ideal for diverse industrial applications.

Robust, Fast, and Reliable Performance

With a long-term stability of 0.2% F.S. per year and a rapid response time of just 1 ms (from 10% to 90%), the SENSO pressure transmitter ensures critical pressure monitoring is both timely and accurate. Its IP65/IP67 ingress protection further guarantees seamless operation in demanding conditions.

FAQ's of SENSO high temperature pressure transmitter upto 150 degree c:

Q: How does the SENSO high temperature pressure transmitter withstand extreme temperatures?

A: The transmitter is designed to operate reliably from -40C up to +150C due to its robust stainless steel 316L body and precise engineering. This allows it to maintain accuracy and durability in challenging, high-temperature industrial environments.

Q: What pressure ranges and process connections are available with this transmitter?

A: The SENSO transmitter supports pressure ranges of 0-10 bar, 0-60 bar, or can be customized to specific needs. For process connections, it offers G1/2'', G1/4'', M201.5, and is also available with customized fittings for universal compatibility.

Q: When should I choose IP65 or IP67 ingress protection for my application?

A: IP65 is suitable for environments with dust and water spray, while IP67 is ideal for applications where the transmitter may be temporarily submerged. Selecting the right protection ensures the device operates optimally based on your installation circumstances.

Q: Where can this transmitter be used regarding media compatibility?

A: Thanks to its 316L stainless steel construction and specialized design, the SENSO transmitter can be safely used with both corrosive and non-corrosive liquids and gases, making it suitable for a wide array of industrial and laboratory settings.

Q: What is the process for customizing output or electrical connections on this device?

A: You can specify requirements for output (4-20 mA or 0-10 V) and electrical connection types (such as DIN43650, Packard, M12x1, or cable outlet) during your order to ensure seamless integration into your existing systems.

Q: How quickly does the SENSO transmitter respond to pressure changes?

A: The device features a response time of just 1 ms (from 10% to 90%), allowing you to monitor and respond to pressure variations in real-time, crucial for precise process control.

Q: What benefits does using a SENSO high temperature pressure transmitter offer?

A: Users benefit from its high accuracy (0.25% F.S.), long-term stability, robust construction, and adaptability to harsh conditions. This ensures reliable operation, reduced maintenance, and accurate data critical for process optimization in industrial applications.
