SENSO Pressure transmitter

Name: SENSO Pressure transmitter
Brand: R S SALES & SERVICES
Price: 5000.0 INR
Availability: InStock

Price 5000.0 INR/ Number

Get a Price/Quote

MOQ : 1 Number

SENSO Pressure transmitter Specification

Product Type
PRESSURE TRANSMITTER

Pressure Medium
Liquid, Gas, Steam

Zero & Span Adjustment
Yes, external

Long Term Stability
0.3 % F.S/year

Repeatability
0.2% F.S.

Ambient Temperature Range
-40C to +85C

Vibration Resistance
10 g, 20 Hz~2000 Hz

Overload Pressure
150% of F.S.

Cable Length
Standard 2 m (customizable)

Body Material
Stainless Steel 316L

Electrical Connection
M12 Connector / Cable Gland

Power Consumption
<1.5 W

Shock Resistance
100g/11ms

Burst Pressure
300% of F.S.

Temperature Coefficient (Zero/Span)
0.03% F.S/C

Response Time
5 ms

Indication
Clear digital status and alarms

Thread Standard
G1/4

SENSO Pressure transmitter Trade Information

Minimum Order Quantity
1 Number

Supply Ability
1000 Per Week

Delivery Time
1 Week

Sample Available
No

Sample Policy
If order is confirmed we will reimburse the sample cost

Packaging Details
BOX

Main Export Market(s)
Asia, Australia, Central America, North America, South America, Eastern Europe, Western Europe, Middle East, Africa

Main Domestic Market
All India

About SENSO Pressure transmitter

The SNSO-11 Series is engineered for precision measurement in demanding industrial and hydraulic environments. Designed to withstand harsh medium influences, this series offers exceptional reliability and long-term stability even when subjected to extreme pressure peaks and cavitation.

High Performance for Demanding Applications

Engineered with a robust stainless steel 316L body and high overload (150% F.S.) and burst pressure (300% F.S.) capability, the SENSO Pressure Transmitter excels in environments requiring durability and reliability. Its advanced piezoresistive sensor technology ensures accurate conversion of mechanical pressure into precise electrical signals for consistent process monitoring.

Versatile Mounting and Connectivity

The transmitter is designed for flexible installation, supporting both threaded (G1/4", 1/2" NPT, custom) and panel mounting. Standard M12 or cable gland electrical connections, with a wired/terminal block interface, allow integration into a variety of industrial systems. Its compact design and 2-meter customizable cable make it easy to fit in restricted spaces.

User-Friendly Features and Maintenance

Featuring a clear LED digital display and digital alarm indication, the device allows for real-time status checks and easy zero & span adjustments. The external adjustment mechanism ensures minimal process downtime during calibration or maintenance, contributing to efficient and hassle-free operation in the field.

FAQ's of SENSO PRESSURE TRANSMITTER:

Q: How does the SENSO Pressure Transmitter ensure measurement accuracy and stability?

A: The transmitter uses a piezoresistive sensor and high-grade electronics to achieve an accuracy of 0.5% F.S., repeatability of 0.2% F.S., and long-term stability of 0.3% F.S./year. Its stainless steel 316L body and robust design further maintain precision in challenging conditions.

Q: What types of media can be measured using this transmitter?

A: It is suitable for liquid, gas, oil, water, and steam measurement, making it versatile for applications in industrial automation, hydraulics, pneumatics, water supply, HVAC, and process control.

Q: When should I perform zero and span adjustments, and how can they be made?

A: Zero and span adjustments should be made during initial setup, calibration, or if you notice measurement drift. This device allows simple external adjustments, minimizing downtime by enabling quick recalibration without removing the unit from the process.

Q: Where should this pressure transmitter be installed for optimal performance?

A: Install the transmitter in a location with direct access to the process medium, using the recommended G1/4" or 1/2" NPT threads. It can be directly or panel-mounted and suits both indoor and outdoor industrial environments, thanks to its IP65 rating and robust enclosure.

Q: What is the process for integrating the transmitter with existing systems?

A: The device supports standard analog outputs (4-20 mA/0-10V) and is compatible with DC power supplies (12-36V DC). Electrical connection is via M12 connector or cable gland, making it straightforward to connect with common PLCs, automation equipment, or monitoring systems.

Q: How does the transmitter handle challenging environmental conditions?

A: With an ambient and operating temperature range of -40C to +85C, vibration resistance of 10g, and shock resistance up to 100g, the transmitter is built to operate reliably in extreme industrial settings. Its IP65 enclosure and corrosion-resistant construction further enhance durability.

Q: What are the key benefits of using the SENSO Pressure Transmitter in industrial applications?

A: Benefits include high measurement precision, robust construction for harsh conditions, excellent long-term stability, overpressure protection, customizable installation, and simple, user-friendly calibration and monitoring through its LED display and external adjustments.
